MOZA CRP2 Load Cell Pedals (Throttle+Brake)
People are viewing this right now
Description
MOZA CRP2 Load Cell Pedals
A high-performance load cell pedal set designed for competitive sim racers. Built with aerospace-grade aluminum and carbon fiber, featuring adjustable resistance, travel, and real-time telemetry for precise control. Includes throttle and brake pedals, with optional clutch available separately.
Key Features
- 2-Pedal Set: Accelerator and brake (optional clutch sold separately).
- 3-Stage Clutch & Load Cell Brake Design (optional).
- Adjustable Resistance and Travel for fully customizable feel.
- Stainless Steel Construction with aerospace-grade aluminum and carbon fiber.
- Hall Sensor + Pressure Sensor Technology for precision input.
- MOZA Pit House Software Support for advanced tuning.
What's in the Box
- MOZA CRP2 Load Cell Pedals (Throttle + Brake)
- Toolkit
- Warranty Card
Technical Specifications
- Pedal Body Material: Aerospace-grade aluminum alloy
- Heel Plate Material: 3K twill carbon fiber
- Base Material: High-strength steel
- Load Cell Sensor Range: 0–200 kg
- Brake Sensor: Load cell sensor and angle sensor
- Angle Sensor Resolution: 15-bit (32768 PPR)
- Brake Pedal Feel: 115 standard adjustments, 1764 optional configurations
- Throttle Adjustment: Two spring options with infinite adjustment
- Clutch Adjustment: Two spring options with infinite adjustment
- Brake Travel Adjustment: 15–20°
- Throttle Travel Adjustment: 15–23°
- Clutch Travel Adjustment: 15–25°
- Pedal Angle Adjustment: 0–15°
- Pedal Face Height Adjustment: Up to 30mm
- Footrest Adjustment: Up to 30mm
- Pedal Curve Adjustment: Adjustable
- Real-time Pedal Output Display: Adjustable
- Pedal Pressure Engagement Point: Adjustable
- Pedal Surface: Biomimetic curved
- Inverted Mounting Kit: Optional
Engineered for precision and endurance, the CRP2 Load Cell Pedals deliver pro-grade control, adjustability, and durability for serious sim racers.
MOZA CRP2 Load Cell Pedals (Throttle+Brake)
$549.00
